PE milk bottles bagging machine

PE bottles have the advantages of large capacity, robustness, portability, recyclability and reusability, which make them occupy a certain position in the beverage packaging industry and are widely used. The automatic bagging machine can pack bottles of various shapes and sizes, and the plastic bag tension can make the packaging operation neatly bundled for easy transport. Manual bagging takes only 10 seconds, and one worker can carry out bagging, handling and other work in the factory.

PE bottle bagging machine suitable range:

Water, beverage, diary product,cosmetics, lubricating oil, pesticide bottles, medicine, chemical, food, daily necessities and other industries

Features:

Lower energy consumption.

Maintenance is easier.

It is a more compact solution.

It is a more economical solution.

The application of misalignment device makes the packing effect more compact and easy to transport.

Servomotor controlled bottle pushing, millimeter precise control of packing looseness and tightness.

The packing bag platform is movable.

Technical parameters:

Host size: 3433LX1300WX2604H(mm)

Conveyor system : 85 mm flexible conveyor system(Recommended)

Weight: Approximately 0.7T

Conveyor system height: 1100土100mm（can be customized）

Bottle height: Height adjustable between 75-290mm; material PET/PE/PP

Production efficiency:Continuous 8-hour production at no less than 95% capacity

Bottle feeding method: Single row bottle feeding

Maximum packaging width: 950mm

Production speed: 7 seconds/row in stable operation, 12 seconds for bag pushing

Power consumption: 2KW, power supply AC3ψ380V

Gas consumption: 6-8kg, 0.5 m³
