PET water bottle bagging machine, replacing the traditional manual packing method, realizes the automatic operation of production line, which greatly saves the labor cost as well as improves the efficiency and benefits. With high packing speed, precise packing accuracy and low energy consumption, the automatic bagging machine
ensures sufficient production capacity and saves cost for enterprises. In the process of production, automatic bagging machine can reliably ensure product hygiene, such as food, medicine packaging, according to the health law ,it does not allow manual
packaging, because it will contaminate the product, and mechanical packaging to avoid direct contact with human hands to ensure the quality of hygiene.
PET water bottle bagging machine, replacing the traditional manual packing method, realizes the automatic operation of production line, which greatly saves the labor cost as well as improves the efficiency and benefits. With high packing speed, precise packing accuracy and low energy consumption, the automatic bagging machine ensures sufficient production capacity and saves cost for enterprises. In the process of production, automatic bagging machine can reliably ensure product hygiene, such as food, medicine packaging, according to the health law ,it does not allow manual packaging, because it will contaminate the product, and mechanical packaging to avoid direct contact with human hands to ensure the quality of hygiene.
Water and beverage industry: mineral water, pure water, juice drink,etc.
Edible oil industry: large barrel special bottle, other packaging specifications;
Cosmetics bottles: customized molds according to customer requirements, providing diversified bottle type specifications.
Pharmaceutical industry: PET material of alcohol bottles and disinfectant bottles.
Functional features:
Automatic rejection of inverted bottles
Automatic waiting for lacking material (optional)
HWF sealing technology, double sealing line sealing uniformity, no damage, sealing knife is not affected by the temperature of the production environment.
The frame adopts national standard 5050 cast iron square steel, high strength, can ensure the long-term stability of the whole machine, seamless welding technology, beautiful and durable.
The servo motor control pushes the bottles, millimetre-level precise control of the tightness of the package, stable and accurate action,
The pushing length and speed of the bottle can be adjusted directly in the automatic work process, greatly reducing the adjustment time of changing the bottle type.
The weight-bearing part of the bag opening device is strong, durable and easy to adjust.
Technical parameters:
Host size: 3433LX1300WX2604H(mm)
Conveyor system : 85 mm flexible conveyor system(Recommended)
Weight: Approximately 0.7T
Conveyor system height: 1100土100mm（can be customized）
Bottle height: Height adjustable between 75-290mm; material PET/PE/PP
Production efficiency:Continuous 8-hour production at no less than 95% capacity
Bottle feeding method: Single row bottle feeding
Maximum packaging width: 950mm
Production speed: 7 seconds/row in stable operation, 12 seconds for bag pushing
Power consumption: 2KW, power supply AC3ψ380V
Gas consumption: 6-8kg, 0.5 m³
